Homography

• Image Homographies



Adjust the angle.

---

Here are several consecutive images taken.



---

Attach these images in order.

Images are put together alternately. This is because the angle of the picture is different.



---

Use Homography to adjust the angle.



---

---

---

It requires 3 conditions.



1. The subject should be plane.

---

2. If it's not a plane, at least it should be close to a plane.

Because even if it's not actually a plane, we'll assume that it's a plane, that is, we'll think of it as a plane.

---

3. The two images must be taken from the same center.

---

• Determining a Homography



Let's determine the Homography between two different images.



1. Convert 2D coordinate(p) to homogeneous coordinates(P).



\begin{equation}p=\begin{bmatrix}x\\y\end{bmatrix}\quad\Rightarrow\quad P=\begin{bmatrix}x\\y\\1\end{bmatrix}\end{equation}



2. Assume there are P' that is matching with P.



\begin{equation}P'=H\cdot P\quad\text{or}\quad\left[\begin{array}{c}x'\\y'\\1\end{array}\right]=\alpha\left[\begin{array}{ccc}h_1&h_2&h_3\\h_4&h_5&h_6\\h_7&h_8&h_9\end{array}\right]\left[\begin{array}{c}x\\y\\1\end{array}\right]\end{equation}
