Perceptron, Step function, Single-Layer Perceptron, Multi-Layer Perceptron, DNN

• Perceptron

It is a linear classifier, an algorithm for supervised learning of binary classifiers.

Input(multiple x)-->Output(one y)

x : input

W : Weight

y : output



Each x has each weights. Larger w, more important x.



• Step function

∑W * x >=threshold(θ)-->output(y) : 1

∑W * x <threshold(θ)-->output(y) : 0

Threshold(θ) can be expressed b(bias) such as

• Single-Layer Perceptron

It can learn only linearly separable patterns.

- And gate

def AND_gate(x1,x2):
  w1=0.5
  w2=0.5
  b=-0.7
  result=x1*w1+x2*w2+b
  if result<=0:
    return 0
  else:
    return 1

AND_gate(0,0),AND_gate(0,1),AND_gate(1,0),AND_gate(1,1)
>>>
(0, 0, 0, 1)



- Nand gate

def NAND_gate(x1,x2):
  w1=-0.5
  w2=-0.5
  b=0.7
  result=x1*w1+x2*w2+b
  if result<=0:
    return 0
  else:
    return 1

NAND_gate(0,0),NAND_gate(0,1),NAND_gate(1,0),NAND_gate(1,1)
>>>
(1, 1, 1, 0)

• Multi-Layer Perceptron

It can learn non-linearly(curb) separable patterns. It enables you to distinguish between the two linearly separable classes.



• DNN

Deep Neural Network, there are more than 2 hidden layers.
